Ternary Lithium Battery Pack for Honda CR-V Hybrid (2023)

 Product Overview

The Ternary Lithium (LiNiCoMnO₂, NCM) Battery is a high-performance, OEM-compatible traction battery exclusively engineered for the Honda CR-V Hybrid 2023 (RT5/RT6 series). Built with advanced high-density NCM ternary lithium cells, it is fully optimized for Honda’s latest fourth-generation i-MMD (Intelligent Multi-Mode Drive) hybrid system. This battery delivers superior energy density, faster charge/discharge response, stronger electric assist, and enhanced regenerative braking efficiency compared to conventional lithium-ion packs. Designed as a direct plug-and-play replacement, it matches the original vehicle’s dimensions, connectors, and BMS (Battery Management System) protocols, ensuring seamless integration and restoring the 2023 CR-V Hybrid’s peak hybrid performance, fuel efficiency, and reliability for daily driving and long-distance use.

2. Key Features

Exclusive 2023 CR-V Hybrid Compatibility: Tailored for Honda CR-V Hybrid 2023 (RT5/RT6 series), fitting all hybrid trims (FWD & AWD) with no modifications required.

Advanced NCM Ternary Lithium Technology: High-energy-density nickel-cobalt-manganese oxide cells, offering 25% higher power density and 15% lighter weight than standard lithium-ion batteries.

4th-Gen i-MMD Optimized: Precision-calibrated for Honda’s latest i-MMD hybrid system, supporting smooth electric assist, rapid regenerative braking, and seamless mode switching (EV, Hybrid, Engine).

Efficient Active Air Cooling: Smart forced air cooling system with integrated temperature sensors, maintaining optimal battery temperature (-25°C to 55°C) for stable performance in extreme climates.

Superior Low-Temperature Performance: Outperforms traditional batteries in frigid conditions, maintaining high discharge efficiency and reliable startup even at -25°C.

OEM-Level Safety Protection: Built-in multi-layer protection (overcharge, over-discharge, over-current, short-circuit, over-temperature) to meet Honda’s strict automotive safety standards.

Seamless BMS Integration: Perfectly matched to the 2023 CR-V Hybrid’s original BMS, ensuring accurate battery monitoring, balanced cell voltage, and extended service life.

Plug-and-Play Installation: Direct replacement with OEM-matched mounting points, waterproof connectors, and wiring harnesses—no drilling or modifications needed.

Long Cycle Life: ≥3,800 charge-discharge cycles (≥80% capacity retention), adapting to the CR-V Hybrid’s shallow-cycle working mode for long-term reliability.

Compact & Lightweight Design: Space-saving structure fits the original battery compartment, reducing vehicle weight and improving overall fuel efficiency.

3. Specifications

Battery Type: Ternary Lithium (NCM) Hybrid Traction Battery

Fitment: Honda CR-V Hybrid 2023 | RT5/RT6 Series | FWD & AWD Trims

Nominal Voltage: 228.0V

Nominal Capacity: 4.5Ah (4500mAh)

Total Energy: ~1.03 kWh

Cell Type: Prismatic NCM ternary lithium cells (LiNiCoMnO₂)

Cooling System: Forced air cooling (active thermal management)

Peak Discharge Rate: 35C (157.5A, 10-second pulse)

Continuous Discharge: 14C (63A, 60-second pulse)

Operating Voltage Range: 200V – 250V

Cycle Life: ≥3,800 cycles (80% DOD, capacity retention ≥80%)

Self-Discharge Rate: ≤2.0% per month (at 25°C)

Operating Temperature: -25°C to 55°C (optimal: 15–35°C)

Protection Functions: Overcharge, over-discharge, over-current, short-circuit, over-temperature

Dimensions (L×W×H): ~690mm × 310mm × 105mm (OEM-matched)

Approximate Weight: ~24 kg

Connector Type: OEM-compatible high-voltage waterproof connectors

Warranty: 3 years / 100,000 km (capacity decay ≤20% within warranty)

Compliance: ISO 9001, IEC 62133, RoHS, Honda OEM quality standards
