LFP Battery Pack for BYD Auto SHARK 07
Specifications
Description
<p>1. Product Overview</p><p>The LFP Blade Battery for the BYD SHARK 07 (also known as BYD Sea Lion 07 EV) is a high-performance lithium iron phosphate power solution tailored for BYD’s mid-size intelligent electric SUV. Offered in two variants—550KM (71.8kWh) and 610KM (80.64kWh) CLTC pure electric range—it integrates BYD’s cutting-edge CTB (Cell-to-Body) technology, e-Platform 3.0 Evo compatibility, and 800V high-voltage fast charging architecture. Engineered for premium urban and long-distance travel, this battery delivers exceptional safety, ultra-fast charging, high energy efficiency, and stable thermal performance, embodying BYD’s latest advancements in LFP chemistry and battery system integration for global mid-size EV markets.</p><p>2. Key Features</p><p>Dual Range Configurations: Two optimized LFP packs offering 550KM (71.8kWh) and 610KM (80.64kWh) CLTC pure electric range to meet diverse user demands.</p><p>Ultra-Safe Blade Cell Design: Rigid flat blade-shaped LFP cells with superior thermal stability; passes strict nail-penetration, crush, and thermal runaway tests without fire or explosion.</p><p>CTB 2.0 Body Integration: Advanced Cell-to-Body technology fuses battery pack with vehicle chassis, enhancing structural rigidity, space utilization, and overall safety.</p><p>800V High-Voltage Fast Charging: 550KM variant supports 180kW DC fast charge; 610KM variant supports 240kW DC fast charge; both charge 10%–80% in just 25 minutes.</p><p>Cobalt & Nickel Free Eco Chemistry: Sustainable LiFePO4 composition using abundant raw materials, lower cost, and minimal environmental footprint.</p><p>Intelligent Liquid Thermal Management: Efficient liquid cooling/heating system with heat pump, maintaining optimal performance from -30°C to 60°C.</p><p>Long Cycle Life: ≥5,000 charge-discharge cycles with ≥80% capacity retention, ensuring extended service life and reduced degradation.</p><p>Upgraded BMS 3.0: Real-time cell monitoring, precision balancing, and multi-lay
Products Description
1. Product Overview
The LFP Blade Battery for the BYD SHARK 07 (also known as BYD Sea Lion 07 EV) is a high-performance lithium iron phosphate power solution tailored for BYD’s mid-size intelligent electric SUV. Offered in two variants—550KM (71.8kWh) and 610KM (80.64kWh) CLTC pure electric range—it integrates BYD’s cutting-edge CTB (Cell-to-Body) technology, e-Platform 3.0 Evo compatibility, and 800V high-voltage fast charging architecture. Engineered for premium urban and long-distance travel, this battery delivers exceptional safety, ultra-fast charging, high energy efficiency, and stable thermal performance, embodying BYD’s latest advancements in LFP chemistry and battery system integration for global mid-size EV markets.
2. Key Features
Dual Range Configurations: Two optimized LFP packs offering 550KM (71.8kWh) and 610KM (80.64kWh) CLTC pure electric range to meet diverse user demands.
Ultra-Safe Blade Cell Design: Rigid flat blade-shaped LFP cells with superior thermal stability; passes strict nail-penetration, crush, and thermal runaway tests without fire or explosion.
CTB 2.0 Body Integration: Advanced Cell-to-Body technology fuses battery pack with vehicle chassis, enhancing structural rigidity, space utilization, and overall safety.
800V High-Voltage Fast Charging: 550KM variant supports 180kW DC fast charge; 610KM variant supports 240kW DC fast charge; both charge 10%–80% in just 25 minutes.
Cobalt & Nickel Free Eco Chemistry: Sustainable LiFePO4 composition using abundant raw materials, lower cost, and minimal environmental footprint.
Intelligent Liquid Thermal Management: Efficient liquid cooling/heating system with heat pump, maintaining optimal performance from -30°C to 60°C.
Long Cycle Life: ≥5,000 charge-discharge cycles with ≥80% capacity retention, ensuring extended service life and reduced degradation.
Upgraded BMS 3.0: Real-time cell monitoring, precision balancing, and multi-layer protection (overcharge, over-discharge, over-current, short-circuit, over-temperature)
High Structural Safety: Meets global top-tier crash standards with reinforced pack enclosure and IP67 dustproof & waterproof rating
Global Regulatory Compliance: Certified to UN ECE R100, EU RoHS, REACH, GB 38031-2025, and Euro NCAP safety standards
3. Specifications
550KM Standard Variant
Battery Type: Lithium Iron Phosphate (LFP) Blade Battery (CTB 2.0)
Fitment: BYD SHARK 07 (Sea Lion 07 EV) 550KM RWD/AWD
CLTC Range: 550KM (Pure Electric)
Gross Capacity: 71.8 kWh
Usable Capacity: ~69 kWh
Cell Format: Blade-shaped (flat rectangular) single cells
Chemistry: LiFePO4 (Cobalt-free, Nickel-free)
Nominal Voltage: 576 V
Configuration: 180S1P (180 series, 1 parallel)
Thermal Management: Liquid cooling + liquid heating + heat pump
DC Fast Charging: Max 180kW (CCS2 port); 10%–80% in ~25 mins
AC On-board Charging: 7kW (Type 2 port); 0%–100% in ~10.26 hrs
Cycle Life: ≥5,000 cycles (≥80% capacity retention)
Operating Temperature: -30°C to 60°C
Safety Features: Nail-penetration safe, thermal runaway protection, crash-resistant structure, IP67 dustproof & waterproof
Standard Warranty: 8 years / 150,000 km / First-owner lifetime warranty (selected regions)
Approximate Pack Weight: ~475 kg
Compliance: UN ECE R100, EU RoHS, REACH, GB 38031-2025, Euro NCAP
610KM Long-Range Variant
Battery Type: Lithium Iron Phosphate (LFP) Blade Battery (CTB 2.0)
Fitment: BYD SHARK 07 (Sea Lion 07 EV) 610KM RWD/AWD
CLTC Range: 610KM (Pure Electric)
Gross Capacity: 80.64 kWh
Usable Capacity: ~78 kWh
Cell Format: Blade-shaped (flat rectangular) single cells
Chemistry: LiFePO4 (Cobalt-free, Nickel-free)
Nominal Voltage: 604.8 V
Configuration: 189S1P (189 series, 1 parallel)
Thermal Management: Liquid cooling + liquid heating + heat pump
DC Fast Charging: Max 240kW (CCS2 port); 10%–80% in ~25 mins
AC On-board Charging: 7kW (Type 2 port); 0%–100% in ~11.52 hrs
Cycle Life: ≥5,000 cycles (≥80% capacity retention)
Operating Temperature: -30°C to 60°C
Safety Features: Nail-penetration safe, thermal runaway protection, crash-resistant structure, IP67 dustproof & waterproof
Standard Warranty: 8 years / 150,000 km / First-owner lifetime warranty (selected regions)
Approximate Pack Weight: ~520 kg
Compliance: UN ECE R100, EU RoHS, REACH, GB 38031-2025, Euro NCAP
